Direct Drive, High Efficiency
750W direct saver motor, compared with the clutch motor, more accurate to control mechanical structure. Also it is power saving and high efficiency machine.
Description
Cantilever Cylindrical Structure
Cylindrical design makes out more beautiful stitch and reduces the wrinkled of fabric. Widely used in Shirt, uniform, jeans, from light duty to heavy duty product.
Lubricated Rear Puller Device Design
Realization of the rear puller lubricated makes the rear puller lubricate continuously, which extends the life of rear puller a lot.
Automatic Needle Position Function
The needle position is always in upside. Convenient to sewing, needle exchanging and thread making.
Removable Needle Guard, Beautiful Stitch
Removable need guard, to prevent the skipping stitch, to make the high quality with high efficiency.
Stitch Length Adjust Button
The button can adjust the stitch length easily to satisfy many different requirements.
LED Light
Easy to thread making, needle changing and relieve visual fatigue.
Different Kinds Of Puller Devise
PL puller device is built-in direct drive puller whose structure is very simple; PS puller is outside which makes the cloth feeding size wider and adjustment convenient.
| Mode | Needle | Needle Number | Thread Number | Stitch Length | Height of Presser Foot（mm） | Thin Material | Mudium-heavy material | Heavy Material | Sewing Speed （S.p.m） | Volume（mm） | Weight(kg) |
| JK-T9270-12(1/4) | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-12(3/16) | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| T9270-12-2PL(1/4) | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-12-2PL（3/16） | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-12-2PL(3/16) | TV×64 12# | 2 | 4 | 4.2 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-12-2PS(1/4) | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-12-2PS(3/16) | TV×64 12# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-13(1/8) | TV×64 12# | 3 | 6 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-13-2PL(1/8) | TV×64 12# | 3 | 6 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-22(1/4) | TV×64 14# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9270-22(3/16) | TV×64 14# | 2 | 4 | 3.5 | 8 | √ | 4000 | 580*535*475 | 40/55 | ||
| JK-T9280-53(1/8) | TV×5 21# | 3 | 6 | 4.2 | 10 | √ | 3600 | 580*535*475 | 40/59 | ||
| JK-T9280-73-2PL(1/8) | TV×5 21# | 3 | 6 | 4.2 | 10 | √ | 3600 | 580*535*475 | 40/59 | ||
| JK-T9280-73-PL(1/8) | TV×5 21# | 3 | 6 | 4.2 | 10 | √ | 3600 | 580*535*475 | 40/59 | ||
| JK-T9280-73-PS(1/8) | TV×5 21# | 3 | 6 | 4.2 | 10 | √ | 3600 | 580*535*475 | 40/59 |
